Engine Type: Single cylinder ,4 stroke, air-cooled & oil-cooled
Bore stroke: 2.07" X 2.04"
Displacement: 120cc
Compression Ratio: 9.5：1
Engine Output Wattage: 110 Watts
MAX POWER OUT: 6.2Kw / 7000rpm
Max Torque: 7.2N.m / 5500rpm
Transmission: CVT, Automatic CVT
W./Reverse Gear: Yes, with gear sets of Forward, Neutral, Reverse
Lubrication Mode: Wet trough lubrication
Oil Capacity: 30.43 Oz
Max Speed: 35mph+ (Depending on Riders Weight and Road Conditions)
Fuel Delivery System: Electronic fuel injection (EFI)
Ignition: AC-CDI
Ignition Timing: 32°±2°@5000RPM
Spark plug gap: 0.6-0.7mm
Starting System: Electric
Drive Train: 2WD
Chain pitch: 13mm
Battery: 12V, 5Ah
Suspension / Front: Traverse Double-arm
Shock / Front: Overall Len. 280mm, outer diameter 53mm, spring diameter 6mm, spring len. 170mm
Suspension / Rear: Flat Fork Dependent
Shock / Rear: Overall Len.325mm, outer diameter 61mm, spring diameter 8mm, spring len. 220mm
Brakes / Front: Reinforced Drum brake
Brakes / Rear: Disc brake
Tires / Front: AT19X7-8 13N, off-road tire
Rim / Front: AT8x5.5 ET=-10, Steel Rim
Tire / Rear: AT18X9.5-8 13N, off-road tire
Rim / Rear: AT8x5.5 ET=-10, Steel Rim
FRAME: Steel Frame elegant PEARL BLACK COLOR
ATV dimensions L x W x H: 62"(L) x 40"(W) x 39"(H)
Carton dimensions L x W x H: 63.8"(L)x38.2"(W)x32.4"(H)
Suggested Rider Weight: 178.6 lbs
Net Weight: 291 lbs
Gross Weight: 295 lbs (If filled with 1L Oil + 0.6L Gear Oil +Brake Oil)
Payload of rack (F and R): F 15 lbs, R 30 lbs
Seat Height: 29"
Wheelbase: 42"
Front Wheel tracy: 34"
Rear Wheel Tracy: 30"
Front Wheel camber: -1°
Min. Ground Clearance: 4"
Fuel Capacity: 7.8L (2 Gallons)
Engine Kill Switch: Yes, also together with pull wire emergency shutdown
Indicator Light: Neutral, Reverse, Fuel Level, Engine Check
Speed Limiter: Yes, connection speed limit, disconnection release speed limit
Horn: Yes
Remote Control: Yes, emergency shut off (Pull Wire)
Headlight: Yes, LED
Tail Light: Yes, LED, Keeps lighting when power lock on
