SPECIFICATIONS:
Overall dimensions（L×W×H）1200mm×745mm×785mm
Wheel base 805mm
front wheel distance 615mm
rear wheel distance 550mm
ground clearance 90mm
Seat height 580mm
Curb weight 86k
grated load mass 70kg
Max speed 24km/h
minimum turning radius 2500mm
maximum gradeability 10°
front brake type front hydraulic brake
rear brake type rear hydraulic brake(with parking brake）
brake operation Front hydraulic brake by hand , rear hydraulic brake by foot pedal
front rim steel rear rim steel
front tire size 145/70-6
rear tire size 145/70-6
front tire air pressure 10P.S.I.
rear tire air pressure 10P.S.I.
transmission Chain
Net weight 75kg
Gross weight 88kg
Engine type 4 stroke, Single cylinder , air cooling
displacement 106.7cc
Bore×Stroke 52.4mm×49.5mm
Max power 5.0kW/7500rpm
Max torque 7.0N.m/5500rpm
ignition CDI
start electric start
fuel grade RQ-93
Engine oil grade SAE15W/40
