engine Brand YX
engine 140cc Air cooled, 4-stroke, single-cylinder
Engine Gear 4-speed Manual (N-1-2-3-4)
Transmission Chain Drive
Shift Gear Hand
Engine Bore X Stroke 56×57mm
compression ratio 9.8：1
max power 11HP/8000r/min
Max torque10.2N.m/7500r/min
Ignition CDI
Engine Oil total capacity 0.24 Gallon
Fuel Tank Capacity 1.03 Gallon
Start way Kick Start
Front wheel 70/100-17Rear wheel90/100-14
Drive train Chain drive
Front and rear absorber brand SYD
Front absorber 30.3 inches Non-Adjustable
Rear absorber 13.8 inches Non-Adjustable
Front Hand Brake Hydraulic Disc
Rear Foot Brake Hydraulic Disc
Frame Double beam Heavy Duty Steel frame
N.W:176 LBS
G.W198 LBS
Products size(L*W*H) 72.4*30.5*46.5 inches
seat height 33 inches
wheel base 48 inches
Ground Clearance1 3 inches
box size(L*W*H) 57.5*15*29.5inches
