ENGINE
Engine Make / Type: Air-Cooled SOHC 4-Stroke 176cc
Top Speed: 35MPH
Lubrication Type: Pressure and Hybrid Splash Lubrication
Max Torque: 10N·m/6000r/min
Compression Ratio: 9.5:1
Valve Configuration: 2 Valve
TRANSMISSION & DRIVE
Drive Type: Fully Automatic
Gears: CVT – F,N,R
Clutching Type: Automatic Centrifugal Dry
Drive line Type: Chain
Starting System: Electric Start
SUSPENSION
Front Suspension: Single A-Arm
Rear Suspension: Rear Single Shaft Swing Arm
BRAKES, TIRES & WHEELS
Front/Rear Brakes: Disc Brakes
Front Tire: 20×7-10
Rear Tire: 19×10-9
Front/Rear Tread: 820mm / 810mm
MEASUREMENTS & DIMENSIONS
ATV Dimensions: 63'(L) x 41'(W) x 41'(H)
Ground Clearance: 5.9in
Wheelbase: 45in
