Vehicle Specification
Overall Length 97.6 in. (2480mm)
Overall Width 61.14 in. (1553mm)
Overall Height 57.5 in.（1460mm）
Front Tire AT21x7-10
Rear Tire AT22x10-10
Wheelbase 68.5 in.(1740mm)
Min. ground clearance 4.7 inch (12cm)
Dry Weigh 586.43lbs (266kg)
Front Suspension Double A-arm
Rear Suspension, Drag arm suspension
Front Brake Dual Hydraulic Disc
Rear Brake Single Hydraulic Disc
Fuel Tank Capacity 2.3gal (8.5L)
Battery 12V 9Ah
Maximum Speed 43.7mph (70km/h)
Engine Specification
Engine Type Four-Stroke, Single Cylinder
Displacement 168.9 cc
Bore & Stroke 61 × 57.8 mm
Compression Ratio9.2：1
Fuel System Electronic Fuel Injection (EFI)
Ignition Electronic Control Unit (ECU)
Transmission Automatic F-N-R
Drive Train CVT belt, Chain drive
Cooling Air cooling
Maximum power 8.3KW/8000RPM
Maximum Torque 11N·m/6000RPM
