Overall Vehicle Size (L x W x H) 83x46x50 in
Ground Clearance (inch) 7.2 in
Wheelbase (inch) 51 in
Weight with full equipment 618 lbs
Front / Rear Brakes Two sides hydraulic disc
Parking Brake Front / Rear hand brake, Foot brake
Front Tires AT24X8-12
Rear Tires AT24X11-10
Front Suspension McPherson independent suspension
Rear Suspension Socket centering structure
Fuel Capacity3.8 gallons
Engine specification
Engine model LH173MN
Engine Type Carburetor, 4 Stroke, Single Cylinder, SOHC, Water Cooling
Bore & stroke 2.85*2.63 in
Volumetric Compression Ratio10.3:1
Displacement 257cc
Drive System Type 2WD or 4WD
Ignition type T.C.I
Start type Electric
Maximum power (Kw /r/min )22 HP @ 6500 RPM
Maximum Torque (Nm /r/min)14.8 lb-ft @ 5500 RPM
Overall Vehicle Size (L x W x H) 83x46x50 in
Ground Clearance (inch) 7.2 in
Wheelbase (inch) 51 in
Weight with full equipment 618 lbs
Front / Rear Brakes Two sides hydraulic disc
Parking Brake Front / Rear hand brake, Foot brake
Front Tires AT24X8-12
Rear Tires AT24X11-10
Front Suspension McPherson independent suspension
Rear Suspension Socket centering structure
Fuel Capacity3.8 gallons
Engine specification
Engine model LH173MN
Engine Type Carburetor, 4 Stroke, Single Cylinder, SOHC, Water Cooling
Bore & stroke 2.85*2.63 in
Volumetric Compression Ratio10.3:1
Displacement 257cc
Drive System Type 2WD or 4WD
Ignition type T.C.I
Start type Electric
Maximum power (Kw /r/min )22 HP @ 6500 RPM
Maximum Torque (Nm /r/min)14.8 lb-ft @ 5500 RPM
